Atomos Shinobi 5" SDI/HDMI HDR Pro Monitor

$40.00
/
7 Day

Rental

Available 12/05/24

Renting this item will adjust your rental dates.

Interested in purchasing?

Includes

  • Atomos Shinobi SDI
  • Battery Eliminator AC Adapter
  • Case

Resources

  • Spec Sheet
  • Atomos Shinobi 5" SDI/HDMI HDR Pro Monitor

    The Atomos Shinobi SDI 5" HDR Pro Monitor is a 5.2-inch 4K SDI/HDMI on-camera monitor that is capable of displaying DCI 4K, UHD 4K, and HD video inputs. Key features include:

    • 10-bit FRC IPS screen with 1000 cd/m² brightness

    • 4K HDMI & 2K SDI input

    • Supports a range of log formats

    • AtomHDR Mode with 10-Stop Dynamic Range

    Read More

    Specifications

    Brand

    Atomos

    Display

    Panel Type

    • IPS-Type LCD
    Display Size
    • 5.2"
    Resolution
    • 1920 × 1080
    Aspect Ratio
    • 16:9
    Touchscreen
    • Yes
    Maximum Brightness
    • 1000 nits / cd/m2
    Bit Depth / Color Support
    • 8-Bit+FRC (1.07 Billion Colors)
    HDR Compatibility
    • Hybrid Log Gamma
    Pixels Per Inch (ppi)
    • 427 ppi
    Color Gamut
    • 100% Rec. 709
    Real-Time LUT Monitoring
    • SDR
    Image Controls
    • Anamorphic De-Squeeze
    • False Color
    • Focus Peaking
    • Histogram
    • Pixel-to-Pixel Zoom
    • RGB Parade
    • Screen Markers
    • Vectorscope
    • Waveform
    • Zebra
    Video
    • 1 x BNC (3G-SDI) Input
    • 1 x HDMI Type A (HDMI 1.4) Input
    Embedded Audio
    • SDI: 8-Channel
    • HDMI: 2-Channel
    Audio I/O
    • 1 × 1/8" / 3.5 mm Headphone Output
    Built-In Speaker
    • None
    Power I/O
    • 1 x Barrel Input
    Other I/O
    • None
    Media/Memory Card Slot
    • Single Slot: SD/SDHC/SDXC

    Gamma Curve
  • ARRI Log C
  • Canon Log
  • Canon Log 2
  • Canon Log 3
  • FujiFilm F-Log
  • HDR-HLG
  • JVC J-Log
  • Panasonic V-Gamut
  • Panasonic V-Log
  • RED IPP2
  • REDlogFilm
  • Rec2020
  • Rec709
  • Sony S-Log
  • Sony S-Log 2
  • Sony S-Log 3
  • General

    Material of Construction

    • Polycarbonate
    Dimensions
    • 5.9 × 3.6 × 1.2″
    Weight
    • 7.97 oz

    Item Type

    Monitoring and Production Monitors

    Monitoring Type

    Monitor

    Mounting

    2 × 1/4"-20 Female

    Operating Temperature

    104°F

    See All

    Includes

    • Atomos Shinobi SDI
    • Battery Eliminator AC Adapter
    • Case

    Specifications

    Brand

    Atomos

    Display

    Panel Type

    • IPS-Type LCD
    Display Size
    • 5.2"
    Resolution
    • 1920 × 1080
    Aspect Ratio
    • 16:9
    Touchscreen
    • Yes
    Maximum Brightness
    • 1000 nits / cd/m2
    Bit Depth / Color Support
    • 8-Bit+FRC (1.07 Billion Colors)
    HDR Compatibility
    • Hybrid Log Gamma
    Pixels Per Inch (ppi)
    • 427 ppi
    Color Gamut
    • 100% Rec. 709
    Real-Time LUT Monitoring
    • SDR
    Image Controls
    • Anamorphic De-Squeeze
    • False Color
    • Focus Peaking
    • Histogram
    • Pixel-to-Pixel Zoom
    • RGB Parade
    • Screen Markers
    • Vectorscope
    • Waveform
    • Zebra
    Video
    • 1 x BNC (3G-SDI) Input
    • 1 x HDMI Type A (HDMI 1.4) Input
    Embedded Audio
    • SDI: 8-Channel
    • HDMI: 2-Channel
    Audio I/O
    • 1 × 1/8" / 3.5 mm Headphone Output
    Built-In Speaker
    • None
    Power I/O
    • 1 x Barrel Input
    Other I/O
    • None
    Media/Memory Card Slot
    • Single Slot: SD/SDHC/SDXC

    Gamma Curve
  • ARRI Log C
  • Canon Log
  • Canon Log 2
  • Canon Log 3
  • FujiFilm F-Log
  • HDR-HLG
  • JVC J-Log
  • Panasonic V-Gamut
  • Panasonic V-Log
  • RED IPP2
  • REDlogFilm
  • Rec2020
  • Rec709
  • Sony S-Log
  • Sony S-Log 2
  • Sony S-Log 3
  • General

    Material of Construction

    • Polycarbonate
    Dimensions
    • 5.9 × 3.6 × 1.2″
    Weight
    • 7.97 oz

    Item Type

    Monitoring and Production Monitors

    Monitoring Type

    Monitor

    Mounting

    2 × 1/4"-20 Female

    Operating Temperature

    104°F

    See All
