ATOMOS Shogun Inferno 4K HDMI / SDI Recorder

Recommended:

ATOMOS Shogun Inferno 4K HDMI / SDI Recorder

As BorrowLenses becomes Lensrentals, we’re committed to making your experience as simple and straightforward as possible.

While we don’t currently offer this product for rental, please get in touch so we can work together to find an alternative.

Specifications

Brand	Atomos
Display	Screen Size 7.1” Resolution 1920 × 1200 Pixel Density 325 PPI High Bright 1500 nits
Inputs/Outputs	Video Inputs Uncompressed 10-bit or 8-bit 422 (camera dependent) 1x HDMI (2.0) 4x 3G SDI (quad link) 1x SDI up to 12G (single link) Video Outputs Uncompressed 10-bit or 8-bit 422 (playback file dependent) 1x HDMI (2.0) 1x 4K-SDI 12G/6G or HD-SDI 3G/1.5G HDMI I/O Formats 2160p (23.98/29.97/59.94) 1080p (23.98/29.97/59.94/119.88) 1080i (59.94) 720 (59.94) SDI I/O Formats 2160p (23.98/29.97/59.94) 1080p (23.98/29.97/59.94/119.88) 1080pSF (23.98/29.97) 1080i (59.97) 720p (59.97) Signal Conversion Cross Conversion: HDMI to SDI or SDI to HDMI Downscaling: 4K UHD to HD (not available in RAW) Additional Inputs/Outputs Audio Input: Video input or balanced XLR breakout cable Audio Output: 3.5mm headphone jack Remote Input: LANC DC Input (6.2 – 16.8v) Genlock/LTC: BNC
Item Type	Monitoring, Recorder, and Production Monitors
Monitoring Type	Monitor
Physical	Dimensions (W x H x D) 8.4 × 5 × 1.8” Weight Recorder: Approximately 1.6 lbs. Recorder with batteries and SSD: Approximately 2.5 lbs. Mounts 2x ¼-20 insets
Power Supply	AC Adapter Atomos/Simsukian AC Adapter (supplied) Battery Type: 2x Hawk-Woods DV-F790 (supplied) Operating Time: Approximately 130 mins. (monitor & record at 4K 30p) Recharge Time: Approximately 345 mins. System: Primary-secondary hot swappable continuous power
Recording	Supported Codecs ProRes Raw ProRes CinemaDNG (up to 30p) Avid DNxHD Modes* 5.7K DCI (EVA1 ProRes Raw only): 5720 × 3016 (23.98/29.97) 4K DCI: 4096 × 2160 (23.98/29.97/59.94/119.88) 4K UHD: 3840 × 2160 (23.98/29.97/59.94/119.88) 2K: 2048 × 1080 (23.98/29.97/59.94/100/120/200/240) *Mode availability may vary. Some cameras may require additional hardware or upgrades for RAW features. Media 2.5” SSD Compatibility based on format, resolution, and frame rate

Specifications

Brand	Atomos
Display	Screen Size 7.1” Resolution 1920 × 1200 Pixel Density 325 PPI High Bright 1500 nits
Inputs/Outputs	Video Inputs Uncompressed 10-bit or 8-bit 422 (camera dependent) 1x HDMI (2.0) 4x 3G SDI (quad link) 1x SDI up to 12G (single link) Video Outputs Uncompressed 10-bit or 8-bit 422 (playback file dependent) 1x HDMI (2.0) 1x 4K-SDI 12G/6G or HD-SDI 3G/1.5G HDMI I/O Formats 2160p (23.98/29.97/59.94) 1080p (23.98/29.97/59.94/119.88) 1080i (59.94) 720 (59.94) SDI I/O Formats 2160p (23.98/29.97/59.94) 1080p (23.98/29.97/59.94/119.88) 1080pSF (23.98/29.97) 1080i (59.97) 720p (59.97) Signal Conversion Cross Conversion: HDMI to SDI or SDI to HDMI Downscaling: 4K UHD to HD (not available in RAW) Additional Inputs/Outputs Audio Input: Video input or balanced XLR breakout cable Audio Output: 3.5mm headphone jack Remote Input: LANC DC Input (6.2 – 16.8v) Genlock/LTC: BNC
Item Type	Monitoring, Recorder, and Production Monitors
Monitoring Type	Monitor
Physical	Dimensions (W x H x D) 8.4 × 5 × 1.8” Weight Recorder: Approximately 1.6 lbs. Recorder with batteries and SSD: Approximately 2.5 lbs. Mounts 2x ¼-20 insets
Power Supply	AC Adapter Atomos/Simsukian AC Adapter (supplied) Battery Type: 2x Hawk-Woods DV-F790 (supplied) Operating Time: Approximately 130 mins. (monitor & record at 4K 30p) Recharge Time: Approximately 345 mins. System: Primary-secondary hot swappable continuous power
Recording	Supported Codecs ProRes Raw ProRes CinemaDNG (up to 30p) Avid DNxHD Modes* 5.7K DCI (EVA1 ProRes Raw only): 5720 × 3016 (23.98/29.97) 4K DCI: 4096 × 2160 (23.98/29.97/59.94/119.88) 4K UHD: 3840 × 2160 (23.98/29.97/59.94/119.88) 2K: 2048 × 1080 (23.98/29.97/59.94/100/120/200/240) *Mode availability may vary. Some cameras may require additional hardware or upgrades for RAW features. Media 2.5” SSD Compatibility based on format, resolution, and frame rate
