BirdDog P240 40X NDI PTZ Camera

$218.00

7 Day

Rental

Arrival Date

Return Date

Pricing Chart

Shipping Rates

Interested in purchasing?

Includes

BirdDog P240 40X NDI PTZ Camera
AC Adapter
Non-Polarized Cable
Infrared Remote
Case

Resources

Manual

BirdDog P240 40X NDI PTZ Camera

The BirdDog P240 40X NDI PTZ Camera is a full NDI camera that’s designed for capturing sharp and vivid images in resolutions up to 1080p60.

40x optical zoom
Full NDI 5.5 support
OLED display
Integrated ND filter

Q & A

Why are my settings and presets being reset when I cycle the camera's power?

You have to set and save your settings and presets in the BirdUI to preserve them when you cycle the camera’s power.

How can I control the camera's movement?

You can control basic camera moves using the BirdDog IR remote, but for more precise control, the BirdDog PTZ Keyboard is available for rent separately.

How can I change the resolution and frame rate?

You can adjust the resolution and frame rate through the WebUI and the IR remote. The dial has been phased out in recent firmware updates and can no longer be used to make adjustments.

Does this rental include a USB audio adapter?

This rental doesn’t include the BirdDog USB audio adapter by default.
If you need a USB audio adapter with your rental, please request it in the Special Instructions box during checkout and we’ll add one to your order at no additional cost.

Specifications

Brand	BirdDog
Camcorder Type	PTZ
Camera Type	Camcorder
Control	Presets 128 via IP, RS-232, VISCA, Pelco-D Move Speed Pan: 0.05 to 100°/sec Tilt: 0.05 to 50°/sec Movement Range Pan: 175° Tilt: -30 to 90° Tally Light Yes Supported Control Protocols IP NDI Pelco-D RS-232 RS-422 VISCA
Environmental	Operating Temperature 14 to 104°F Operating Humidity 80%
Exposure Control	Shutter Type Electronic Rolling Shutter Shutter Speed 1 to 10,000 Seconds Signal-to-Noise Ratio 50 dB Minimum Illumination 0.4 Lux Flip / Mirror Support Image Flip, Mirror (Vertical)
General	Dimensions (W x H x D) 9.1 × 7.8 × 6.4″ Weight 5.280 lb
Imaging	Sensor Type 1/2.5"-Type CMOS Sensor Sensor Resolution Effective: 8.5 Megapixel IR Cut Filter Yes Built-In ND Filter Mechanical Filter Wheel with Clear ND Filters Focus Control Autofocus Manual Focus
Interface	Video I/O 1 x BNC (3G-SDI) Output 1 x HDMI Output Audio I/O 1 x LEMO 10-Pin Mic/Line (+48 V Phantom Power) Input/Output 1 × 1/8" / 3.5 mm TRS Stereo Input 1 × 1/8" / 3.5 mm TRS Stereo Output Other I/O 1 x NDI (NDI) Control/Video Input/Output 1 x RJ45 (RS-232) Input 1 x RJ45 (RS-422) Input 1 x USB-A (USB 2.0)
Item Type	Camera and PTZ Cameras
Lens	Focal Length 4.4 to 88.4mm Optical Zoom Ratio 40x Field of View Horizontal: 70.2 to 4.1° Maximum Aperture f/2 to 3.8
Power	PoE Support PoE+ 802.3at Power I/O 1 x Barrel (12VDC) Input Power Consumption 22.5 W
Video Capture	External Recording Modes SDI/BNC / HDMI / RJ45 1920 × 1080 at 23.98/25/29.97/50/59.94 fps 1920 × 1080 1280 × 720 at 50/59.94 fps Embedded Audio HDMI/NDI/SDI Audio Recording Yes IP Streaming H.264, NDI\|HX, RTMP, RTSP, SRT 1920 × 1080 at 23.98p, 25p, 29.97p, 50p, 59.94p

See All

Includes

BirdDog P240 40X NDI PTZ Camera
AC Adapter
Non-Polarized Cable
Infrared Remote
Case

Specifications

Brand	BirdDog
Camcorder Type	PTZ
Camera Type	Camcorder
Control	Presets 128 via IP, RS-232, VISCA, Pelco-D Move Speed Pan: 0.05 to 100°/sec Tilt: 0.05 to 50°/sec Movement Range Pan: 175° Tilt: -30 to 90° Tally Light Yes Supported Control Protocols IP NDI Pelco-D RS-232 RS-422 VISCA
Environmental	Operating Temperature 14 to 104°F Operating Humidity 80%
Exposure Control	Shutter Type Electronic Rolling Shutter Shutter Speed 1 to 10,000 Seconds Signal-to-Noise Ratio 50 dB Minimum Illumination 0.4 Lux Flip / Mirror Support Image Flip, Mirror (Vertical)
General	Dimensions (W x H x D) 9.1 × 7.8 × 6.4″ Weight 5.280 lb
Imaging	Sensor Type 1/2.5"-Type CMOS Sensor Sensor Resolution Effective: 8.5 Megapixel IR Cut Filter Yes Built-In ND Filter Mechanical Filter Wheel with Clear ND Filters Focus Control Autofocus Manual Focus
Interface	Video I/O 1 x BNC (3G-SDI) Output 1 x HDMI Output Audio I/O 1 x LEMO 10-Pin Mic/Line (+48 V Phantom Power) Input/Output 1 × 1/8" / 3.5 mm TRS Stereo Input 1 × 1/8" / 3.5 mm TRS Stereo Output Other I/O 1 x NDI (NDI) Control/Video Input/Output 1 x RJ45 (RS-232) Input 1 x RJ45 (RS-422) Input 1 x USB-A (USB 2.0)
Item Type	Camera and PTZ Cameras
Lens	Focal Length 4.4 to 88.4mm Optical Zoom Ratio 40x Field of View Horizontal: 70.2 to 4.1° Maximum Aperture f/2 to 3.8
Power	PoE Support PoE+ 802.3at Power I/O 1 x Barrel (12VDC) Input Power Consumption 22.5 W
Video Capture	External Recording Modes SDI/BNC / HDMI / RJ45 1920 × 1080 at 23.98/25/29.97/50/59.94 fps 1920 × 1080 1280 × 720 at 50/59.94 fps Embedded Audio HDMI/NDI/SDI Audio Recording Yes IP Streaming H.264, NDI\|HX, RTMP, RTSP, SRT 1920 × 1080 at 23.98p, 25p, 29.97p, 50p, 59.94p
