Teradek Bolt 6 LT 750 3G-SDI/HDMI Receiver (Gold Mount)

$121.00

7 Day

Rental

Arrival Date

Return Date

Pricing Chart

Shipping Rates

Interested in purchasing?

Includes

Teradek Bolt 6 LT 750 Receiver (Gold Mount)
(5) Antennas
5/8 Receiver w/ 1/4-20 Threading
Gold Mount Plate (Female)
Gold Mount Plate (Male)
AC Adapter
2-pin LEMO D-Tap Cable
USB 2.0 A Male to Micro B

Resources

Manual

Teradek Bolt 6 LT 750 3G-SDI/HDMI Receiver (Gold Mount)

The Teradek Bolt 6 LT 750 3G-SDI/HDMI Receiver (Gold Mount) enables you to receive 4K30 HD video from up to 750 feet away and includes a Gold Mount battery plate for fuel. Key features include:

Supports new 6 GHz frequency band
SDI & HDMI outputs with zero delay
Receive 4K30 video
Gold Mount battery plate

Q & A

Is there a V-Mount version of this receiver?

Absolutely! You can find it here.

Is this receiver compatible with other Bolt series?

Yep! It’s compatible with previous Bolt 6 and Bolt 4K devices!

Are Gold Mount batteries included in this rental?

Nah, but we have a huge selection of GM batteries available for rent. Check out the recommended section of your screen for options!

Specifications

Brand	Teradek
Environmental	IP Rating None Operating Temperature 32 to 72°F
Format Support	Audio Format 2-Channel 24-Bit 48 kHz Timecode Support Yes
Frequency Range	Non-DFS Frequencies US: 5.94 to 6.42 GHz US: 5.19 to 5.23 GHz US: 5.75 to 5.79 GHz DFS Frequencies US: 5.27 to 5.67 GHz
General	Material of Construction Aluminum, Polycarbonate Dimensions 4.8 × 3.7 × 1.1″ Weight 10.3 oz
Inputs/Outputs	Antenna I/O 5 x RP-SMA Female Video I/O 1 x HDMI 1.4b Output 1 x BNC (3G-SDI) Output Embedded Audio HDMI: 2-Channel SDI: 2-Channel Audio I/O None Power I/O 1 x LEMO 2-Pin (28 VDC) Input Other I/O 1 x Micro-USB Input Encryption 256-Bit AES
Item Type	Monitoring
Monitoring Type	Wireless
Mounting	1 × 1/4"-20 Female 1 × 3/8"-16 Female
Power	DC Input Power 6 to 28 VDC Battery Type 1 x Gold Mount (Interchangeable Mount) Power Consumption 11 W
System	Bolt 6
Video Format	HDMI (10-Bit 4:4:4/4:2:2 RGB, YCC) UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 480p: 60/59.94 576i: 50 480i: 59.94 SDI (10-Bit 4:4:4/4:2:2 RGB, YCC) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 576i: 50 480p: 60/59.94 480i: 59.94
Wireless	Wireless Range 750’ Channel Bandwidth 40 MHz, 20 MHz Latency <0.01 ms RF Power 21 dBm Wi-Fi None Bluetooth Yes

See All

Includes

Teradek Bolt 6 LT 750 Receiver (Gold Mount)
(5) Antennas
5/8 Receiver w/ 1/4-20 Threading
Gold Mount Plate (Female)
Gold Mount Plate (Male)
AC Adapter
2-pin LEMO D-Tap Cable
USB 2.0 A Male to Micro B

Specifications

Brand	Teradek
Environmental	IP Rating None Operating Temperature 32 to 72°F
Format Support	Audio Format 2-Channel 24-Bit 48 kHz Timecode Support Yes
Frequency Range	Non-DFS Frequencies US: 5.94 to 6.42 GHz US: 5.19 to 5.23 GHz US: 5.75 to 5.79 GHz DFS Frequencies US: 5.27 to 5.67 GHz
General	Material of Construction Aluminum, Polycarbonate Dimensions 4.8 × 3.7 × 1.1″ Weight 10.3 oz
Inputs/Outputs	Antenna I/O 5 x RP-SMA Female Video I/O 1 x HDMI 1.4b Output 1 x BNC (3G-SDI) Output Embedded Audio HDMI: 2-Channel SDI: 2-Channel Audio I/O None Power I/O 1 x LEMO 2-Pin (28 VDC) Input Other I/O 1 x Micro-USB Input Encryption 256-Bit AES
Item Type	Monitoring
Monitoring Type	Wireless
Mounting	1 × 1/4"-20 Female 1 × 3/8"-16 Female
Power	DC Input Power 6 to 28 VDC Battery Type 1 x Gold Mount (Interchangeable Mount) Power Consumption 11 W
System	Bolt 6
Video Format	HDMI (10-Bit 4:4:4/4:2:2 RGB, YCC) UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 480p: 60/59.94 576i: 50 480i: 59.94 SDI (10-Bit 4:4:4/4:2:2 RGB, YCC) 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 576i: 50 480p: 60/59.94 480i: 59.94
Wireless	Wireless Range 750’ Channel Bandwidth 40 MHz, 20 MHz Latency <0.01 ms RF Power 21 dBm Wi-Fi None Bluetooth Yes

See All

Resources

Manual

Reviews

See Reviews

Rental Period	Lenscap+	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$27.00	$85.00	$112.00	$37.33
4 days	$29.00	$91.00	$120.00	$30.00
7 days	$39.00	$121.00	$160.00	$22.86
10 days	$53.00	$163.00	$216.00	$21.60
14 days	$68.00	$212.00	$280.00	$20.00
21 days	$92.00	$284.00	$376.00	$17.90
30 days	$115.00	$357.00	$472.00	$15.73
45 days	$150.00	$466.00	$616.00	$13.69
60 days	$176.00	$545.00	$721.00	$12.02
90 days	$226.00	$702.00	$928.00	$10.31

Rental Period	Lenscap	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$18.00	$85.00	$103.00	$34.33
4 days	$20.00	$91.00	$111.00	$27.75
7 days	$26.00	$121.00	$147.00	$21.00
10 days	$35.00	$163.00	$198.00	$19.80
14 days	$46.00	$212.00	$258.00	$18.43
21 days	$61.00	$284.00	$345.00	$16.43
30 days	$77.00	$357.00	$434.00	$14.47
45 days	$100.00	$466.00	$566.00	$12.58
60 days	$117.00	$545.00	$662.00	$11.03
90 days	$151.00	$702.00	$853.00	$9.48

Rental Period	Rental Price	Price Per Day (Approx.)
3 days	$85.00	$28.33
4 days	$91.00	$22.75
7 days	$121.00	$17.29
10 days	$163.00	$16.30
14 days	$212.00	$15.14
21 days	$284.00	$13.52
30 days	$357.00	$11.90
45 days	$466.00	$10.36
60 days	$545.00	$9.08
90 days	$702.00	$7.80

FedEx 2Day	Calculating Shipping
FedEx Standard Overnight	Calculating Shipping
UPS Ground	Calculating Shipping
UPS Next Day Air	Calculating Shipping
