AJA Dante AV 12G-SDI/HDMI 4K Transmitter

$165.00

/

7 Day

Rental

Arrival Date

Return Date

Interested in purchasing?

Includes

AJA Dante AV 12G-SDI/HDMI 4K Transmitter
AC Adapter
3 Prong Power Cord 6ft
Portabrace Stuff Sack

Resources

Controller Guide

Plugin Placement Guide

Quick Start Guide

Recommended:

AJA Dante AV 12G-SDI/HDMI 4K Transmitter

The AJA Dante AV 12G-SDI/HDMI 4K Transmitter is the compatible transmitter for the Dante AV 12G-SDI/HDMI 4K Receiver. Key features include:

Supports PoE+
(2) USB-A Ports, Mini-USB host port
(1) 12G-SDI and (1) HDMI 2.0 input
Low latency

Specifications

Brand	AJA
Environmental	Operating Temperature 32 to 104°F Storage Temperature -40 to 140°F Operating Humidity 10 to 90% (Non-Condensing)
Format Support	Input Audio Format LPCM (Linear Pulse-Code Modulation): 48 kHz / 24-Bit Embedded Audio SDI Input: 8-Channel HDMI Input: 8-Channel
General	Certifications FCC, CE *as per Manufacturer Dimensions 8.74 × 7.09 × 1.65″ / 22.2 × 18.01 × 4.19 cm Weight 3.1 lb
Hardware	Tally Light Yes Wi-Fi Yes OS Compatibility Windows macOS *As of April, 2023: Check with manufacturer for the most up-to-date compatibility
Input Video Format	SDI (10-Bit 4:2:2 YCC) DCI 4K 23.98/24/25/29.97/30/50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25/29.97/30/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 720p 50/59.94/60 fps HDMI (8/10/12-Bit 4:4:4 RGB, YCC) DCI 4K 23.98/24/25/29.97/30/50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25/29.97/30/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 720p 50/59.94/60 fps HDMI / SDI (8-Bit 4:4:4) WUXGA (1920 × 1200) 60 fps UXGA (1600 × 1200) 60 fps SXVGA (1280 × 1024) 60 fps XGA (1024 × 768) 60 fps SVGA (800 × 600) 60 fps VGA (640 × 480) 60 fps
Inputs/Outputs	Video Inputs 1 x HDMI (2.0) Female 1 x BNC (12G-SDI) Female Audio Inputs None Audio Outputs 1 × 2RCA Analog Female Other I/O 1 x BNC Reference Output 1 x RJ45 LAN, PoE 1 x RJ45 LAN 1 x DE-9/DB-9 RS-422 Input 2 x USB-A 1 x Mini-USB Input 1 × 1/8" / 3.5 mm IR Input 1 × 1/8" / 3.5 mm IR Output Expansion Slots None Latency 0.5 Frame
Item Type	Monitoring and Signal Converters
Monitoring Type	Accessories
Power	Power I/O 1 x DIN 4-Pin (12 VDC) Input PoE Support PoE+ 802.3at Power Consumption Power Supply: 100 to 240 VAC at 1.5 A
Supported Standards	Video Standard Compliance SMPTE 292M/424M/425M-A/ST-2081/ST-2082 HDCP Support Version 2.2 EDID Support None HDR Compatibility None

Includes

AJA Dante AV 12G-SDI/HDMI 4K Transmitter
AC Adapter
3 Prong Power Cord 6ft
Portabrace Stuff Sack

Specifications

Brand	AJA
Environmental	Operating Temperature 32 to 104°F Storage Temperature -40 to 140°F Operating Humidity 10 to 90% (Non-Condensing)
Format Support	Input Audio Format LPCM (Linear Pulse-Code Modulation): 48 kHz / 24-Bit Embedded Audio SDI Input: 8-Channel HDMI Input: 8-Channel
General	Certifications FCC, CE *as per Manufacturer Dimensions 8.74 × 7.09 × 1.65″ / 22.2 × 18.01 × 4.19 cm Weight 3.1 lb
Hardware	Tally Light Yes Wi-Fi Yes OS Compatibility Windows macOS *As of April, 2023: Check with manufacturer for the most up-to-date compatibility
Input Video Format	SDI (10-Bit 4:2:2 YCC) DCI 4K 23.98/24/25/29.97/30/50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25/29.97/30/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 720p 50/59.94/60 fps HDMI (8/10/12-Bit 4:4:4 RGB, YCC) DCI 4K 23.98/24/25/29.97/30/50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25/29.97/30/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 720p 50/59.94/60 fps HDMI / SDI (8-Bit 4:4:4) WUXGA (1920 × 1200) 60 fps UXGA (1600 × 1200) 60 fps SXVGA (1280 × 1024) 60 fps XGA (1024 × 768) 60 fps SVGA (800 × 600) 60 fps VGA (640 × 480) 60 fps
Inputs/Outputs	Video Inputs 1 x HDMI (2.0) Female 1 x BNC (12G-SDI) Female Audio Inputs None Audio Outputs 1 × 2RCA Analog Female Other I/O 1 x BNC Reference Output 1 x RJ45 LAN, PoE 1 x RJ45 LAN 1 x DE-9/DB-9 RS-422 Input 2 x USB-A 1 x Mini-USB Input 1 × 1/8" / 3.5 mm IR Input 1 × 1/8" / 3.5 mm IR Output Expansion Slots None Latency 0.5 Frame
Item Type	Monitoring and Signal Converters
Monitoring Type	Accessories
Power	Power I/O 1 x DIN 4-Pin (12 VDC) Input PoE Support PoE+ 802.3at Power Consumption Power Supply: 100 to 240 VAC at 1.5 A
Supported Standards	Video Standard Compliance SMPTE 292M/424M/425M-A/ST-2081/ST-2082 HDCP Support Version 2.2 EDID Support None HDR Compatibility None

Resources

Controller Guide

Plugin Placement Guide

Quick Start Guide
