Blackmagic Design HyperDeck Studio HD Plus

$55.00

7 Day

Rental

Arrival Date

Return Date

Pricing Chart

Shipping Rates

Interested in purchasing?

Includes

HyperDeck Studio HD Plus
6-foot Cat6A Ethernet cable
3-prong universal power cord
Carry case

Resources

Software

Manual

Blackmagic Design HyperDeck Studio HD Plus

The Blackmagic Design HyperDeck Studio HD Plus is a compact HDMI and 6G-SDI capable external capture and play back device for Blackmagic ATEM switchers that records to UHS-II SD bays. Key features include:

Desktop broadcast deck for capture / playback over 6G-SDI or HDMI 2.0
Records uncompressed 10-bit, ProRes, or DNx to dual UHS-II SD card bays
Compatible with all ATEM switchers
On-board display and illuminated controls

Q & A

Will I need anything else?

This rental does not include SD media, HDMI, SDI, or USB cables, or an ATEM switcher.
When used with an ATEM switcher, you will need some form of ethernet hub (not included). If you have any questions about using the HyperDeck with your existing network contact us and a tech will be happy to help you determine if this is the right gear for you.

Can I plug headphones into this thing?

Yes! This device is equipped with a single 1/4" audio outputs for direct monitoring.
Need a 1/4" to 1/8" adapter for your headphones? No problem! While we don’t include an adapter by default, we will add one at no additional cost when requested in the special instructions box at checkout!

How many HyperDecks can be connected to a single ATEM?

You can connect up to four HyperDecks to any ATEM running firmware version 6.8 or newer.

Specifications

Audio Inputs	Analog None Digital SDI 16x channels embedded HDMI 8x channels embedded
Audio Outputs	Analog 1/4" phono Digital SDI 16x channels embedded HDMI 8x channels embedded
Audio Type	Switching
Brand	Blackmagic
Codec / Format Support	Uncompressed QuickTime (up to DCI 4K/30p) Apple ProRes 422 (HQ) QuickTime ProRes 422 QuickTime ProRes 422 (LT) QuickTime ProRes 422 (Proxy) QuickTime Avid DNxHD QuickTime Avid DNxHD MXF
Color Precision	10-bit
Color Space	REC 601, REC 709, REC 2020. 33 point 3D LUTS can be applied to SDI monitor out.
Computer Interface	USB Type-C 3.0 (up to 5Gb/s) for external drive recording, webcam out, software configuration and updates.
Copy Protection	HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
Device Control	Sony compatible RS-422 deck control in / out
Display	Built-in LCD for video, audio and timecode monitoring
Formats	SD NTSC/PAL 525 29.97 / 625 25 (525 59.94i / 625 50i) HD 720p 50/59.94/60 1080i 50/59.94/60 1080PsF 23.98/24/25/29.97/30 1080p 23.98/24/25/29.97/30/50/59.94/60 2K 2560×1440 23.98/24/25/29.97/30 UHD 4K 3840 × 2160p 23.98/24/25/29.97/30 DCI 4K 4096×2160 23.98/24/25/29.97/30
Item Type	Switcher and Recording Deck
Memory Card Slot	(2) UHS-I / II SDXC media slot
Multiple Rate Support	Auto detection of SD, HD and 6G‑SDI.
Recorder Configuration	Via user interface or Blackmagic HyperDeck Ethernet Protocol
SDI Compliance	SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1, SMPTE 2082‑10, SMPTE 2084 and SMPTE 2108‑1
SDI Metadata Support	HD RP188 and closed captioning CEA‑708. HDR Metadata supported on SDI.
Sample Rate	Video: 4:2:2, Audio: 48kHz/24-bit
Sync Input	Blackburst or Tri-Sync
Video Inputs	Digital Video 6G-SDI HDMI 2.0 type A
Video Output	Digital Video (2) 12G-SDI SDI Loop-Through SDI Monitor Output HDMI 2.0 type A

See All

Includes

HyperDeck Studio HD Plus
6-foot Cat6A Ethernet cable
3-prong universal power cord
Carry case

Specifications

Audio Inputs	Analog None Digital SDI 16x channels embedded HDMI 8x channels embedded
Audio Outputs	Analog 1/4" phono Digital SDI 16x channels embedded HDMI 8x channels embedded
Audio Type	Switching
Brand	Blackmagic
Codec / Format Support	Uncompressed QuickTime (up to DCI 4K/30p) Apple ProRes 422 (HQ) QuickTime ProRes 422 QuickTime ProRes 422 (LT) QuickTime ProRes 422 (Proxy) QuickTime Avid DNxHD QuickTime Avid DNxHD MXF
Color Precision	10-bit
Color Space	REC 601, REC 709, REC 2020. 33 point 3D LUTS can be applied to SDI monitor out.
Computer Interface	USB Type-C 3.0 (up to 5Gb/s) for external drive recording, webcam out, software configuration and updates.
Copy Protection	HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
Device Control	Sony compatible RS-422 deck control in / out
Display	Built-in LCD for video, audio and timecode monitoring
Formats	SD NTSC/PAL 525 29.97 / 625 25 (525 59.94i / 625 50i) HD 720p 50/59.94/60 1080i 50/59.94/60 1080PsF 23.98/24/25/29.97/30 1080p 23.98/24/25/29.97/30/50/59.94/60 2K 2560×1440 23.98/24/25/29.97/30 UHD 4K 3840 × 2160p 23.98/24/25/29.97/30 DCI 4K 4096×2160 23.98/24/25/29.97/30
Item Type	Switcher and Recording Deck
Memory Card Slot	(2) UHS-I / II SDXC media slot
Multiple Rate Support	Auto detection of SD, HD and 6G‑SDI.
Recorder Configuration	Via user interface or Blackmagic HyperDeck Ethernet Protocol
SDI Compliance	SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1, SMPTE 2082‑10, SMPTE 2084 and SMPTE 2108‑1
SDI Metadata Support	HD RP188 and closed captioning CEA‑708. HDR Metadata supported on SDI.
Sample Rate	Video: 4:2:2, Audio: 48kHz/24-bit
Sync Input	Blackburst or Tri-Sync
Video Inputs	Digital Video 6G-SDI HDMI 2.0 type A
Video Output	Digital Video (2) 12G-SDI SDI Loop-Through SDI Monitor Output HDMI 2.0 type A

See All

Resources

Software

Manual

Reviews

See Reviews

Rental Period	Lenscap+	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$11.00	$39.00	$50.00	$16.67
4 days	$11.00	$41.00	$52.00	$13.00
7 days	$15.00	$55.00	$70.00	$10.00
10 days	$20.00	$74.00	$94.00	$9.40
14 days	$26.00	$96.00	$122.00	$8.71
21 days	$35.00	$129.00	$164.00	$7.81
30 days	$44.00	$162.00	$206.00	$6.87
45 days	$58.00	$212.00	$270.00	$6.00
60 days	$68.00	$248.00	$316.00	$5.27
90 days	$87.00	$319.00	$406.00	$4.51

Rental Period	Lenscap	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$7.00	$39.00	$46.00	$15.33
4 days	$8.00	$41.00	$49.00	$12.25
7 days	$10.00	$55.00	$65.00	$9.29
10 days	$14.00	$74.00	$88.00	$8.80
14 days	$18.00	$96.00	$114.00	$8.14
21 days	$24.00	$129.00	$153.00	$7.29
30 days	$30.00	$162.00	$192.00	$6.40
45 days	$39.00	$212.00	$251.00	$5.58
60 days	$45.00	$248.00	$293.00	$4.88
90 days	$58.00	$319.00	$377.00	$4.19

Rental Period	Rental Price	Price Per Day (Approx.)
3 days	$39.00	$13.00
4 days	$41.00	$10.25
7 days	$55.00	$7.86
10 days	$74.00	$7.40
14 days	$96.00	$6.86
21 days	$129.00	$6.14
30 days	$162.00	$5.40
45 days	$212.00	$4.71
60 days	$248.00	$4.13
90 days	$319.00	$3.54
