RED EPIC-W HELIUM 8K S35 Brain

$545.00

7 Day

Rental

Arrival Date

Return Date

Pricing Chart

Shipping Rates

Interested in purchasing?

Includes

RED EPIC-W Brain w/integrated media bay
AC Power Adapter (DSMC) w/power cable
DSMC2 Base Expander
DSMC2 Lemo A Adapter
DSMC2 Standard OLPF (installed)

Resources

Helium Operation Guide

Sample R3D Files

Red Tools

RED EPIC-W HELIUM 8K S35 Brain

The RED EPIC-W HELIUM 8K S35 Brain is a high-resolution cinema camera that introduces a lot of key features, including:

8K resolution at 8192 × 4320
275 MB/s data-transfer rates
DSMC2 Interchangeable OLPF system for greater versatility
Fully compatible with RED DSMC2 components

Q & A

What do I need to operate this camera?

At minimum, you’ll need these items to operate this camera: a RED DSMC Lens Mount; a RED Mini-Mag SSD; a RED Mini-Mag Station; and a menu-interface solution such as the RED DSMC2 Sidekick (external monitor required for live view), a RED Touch LCD, or a DSMC2 Touch LCD.

Are there any known power compatibility issues with this brain?

Wooden Cable-less battery plates used with DSMC2 brains running firmware version 7.1 or newer require a firmware update to the plate before it can be recognized as a compatible module by the camera.
We’ve updated our copies in-house so if you rent a DSMC2 brain and cable-less plate from us, you’re all set! If you source a cable-less plate from somewhere else, you can go here for instructions on how to update the plate yourself.

Does this rental include a lens mount?

This rental does not include a lens mount. Links to available lens mounts can be found under the “Recommended” tab on the left side of this page or by searching here.

Specifications

Audio	Integrated dual-channel digital stereo microphones Sampling: Uncompressed 24-bit, 48 kHz
Brand	RED
Camcorder Type	Cinema
Camera Type	Camcorder
Data Rates	Up to 275 MB/s using RED MINI-MAG (480GB & 960GB) Up to 225 MB/s using RED MINI-MAG (120GB & 240GB)
Dynamic Range	16.5+ stops
Item Type	Camera and Cinema Cameras
Maximum Frame Rates	Full Format (1.9:1): 8K (8192 × 4320): 30 fps 7K (7168 × 3780): 30 fps 6K (6144 × 3240): 75 fps 5K (5120 × 2700): 96 fps 4K (4096 × 2160): 120 fps 3K (3072 × 1620): 150 fps 2K (2048 × 1080): 240 fps Scope (2.4:1): 8K (8192 × 3456): 30 fps 7K (7168 × 3024): 40 fps 6K (6144 × 2592): 100 fps 5K (5120 × 2160): 120 fps 4K (4096 × 1782): 150 fps 3K (3072 × 1296): 200 fps 2K (2048 × 864): 300 fps *REDCODE values and max frame rates may vary based on selected acquisition format, aspect ratio, project time base, and SSD.
Memory Type	Red Mini-Mag
Recommended For	Premium Cine and Premium Cine
Recording Formats	REDCODE RAW (available compression ratios): 6:1-22:1 REDCODE for 8K Full Format (8192 × 4320) at 24 fps 7:1-22:1 REDCODE for 8K Full Format (8192 × 4320) at 30 fps 2:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 24 fps 4:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 60 fps Compression ratios and resolutions are limited to recording data rate limitations. Apple ProRes:* 4096 × 2160 ProRes 422 LT/422/422 HQ up to 29.97 fps 2048 × 1080 ProRes 422 LT/422/422 HQ/4444/4444 XQ up to 120 fps AVID DNx: 4096 × 2160 DNxHR 8-bit HQ/SQ/LB, 12-bit HQX up to 29.97 fps 2048 × 1080 DNxHR 12-bit 444 up to 120 fps 1920 × 1080 DNxHD 8-bit HQ/SQ/LB, 10-bit 444/HQX up to 120 fps
Sensor Size	29.90 mm x 15.77 mm (Diagonal: 33.80 mm)
Sensor Type	HELIUM 35.4 Megapixel CMOS
Weight	3.35 lbs (BRAIN with Integrated Media Bay)

See All

Includes

RED EPIC-W Brain w/integrated media bay
AC Power Adapter (DSMC) w/power cable
DSMC2 Base Expander
DSMC2 Lemo A Adapter
DSMC2 Standard OLPF (installed)

Specifications

Audio	Integrated dual-channel digital stereo microphones Sampling: Uncompressed 24-bit, 48 kHz
Brand	RED
Camcorder Type	Cinema
Camera Type	Camcorder
Data Rates	Up to 275 MB/s using RED MINI-MAG (480GB & 960GB) Up to 225 MB/s using RED MINI-MAG (120GB & 240GB)
Dynamic Range	16.5+ stops
Item Type	Camera and Cinema Cameras
Maximum Frame Rates	Full Format (1.9:1): 8K (8192 × 4320): 30 fps 7K (7168 × 3780): 30 fps 6K (6144 × 3240): 75 fps 5K (5120 × 2700): 96 fps 4K (4096 × 2160): 120 fps 3K (3072 × 1620): 150 fps 2K (2048 × 1080): 240 fps Scope (2.4:1): 8K (8192 × 3456): 30 fps 7K (7168 × 3024): 40 fps 6K (6144 × 2592): 100 fps 5K (5120 × 2160): 120 fps 4K (4096 × 1782): 150 fps 3K (3072 × 1296): 200 fps 2K (2048 × 864): 300 fps *REDCODE values and max frame rates may vary based on selected acquisition format, aspect ratio, project time base, and SSD.
Memory Type	Red Mini-Mag
Recommended For	Premium Cine and Premium Cine
Recording Formats	REDCODE RAW (available compression ratios): 6:1-22:1 REDCODE for 8K Full Format (8192 × 4320) at 24 fps 7:1-22:1 REDCODE for 8K Full Format (8192 × 4320) at 30 fps 2:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 24 fps 4:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 60 fps Compression ratios and resolutions are limited to recording data rate limitations. Apple ProRes:* 4096 × 2160 ProRes 422 LT/422/422 HQ up to 29.97 fps 2048 × 1080 ProRes 422 LT/422/422 HQ/4444/4444 XQ up to 120 fps AVID DNx: 4096 × 2160 DNxHR 8-bit HQ/SQ/LB, 12-bit HQX up to 29.97 fps 2048 × 1080 DNxHR 12-bit 444 up to 120 fps 1920 × 1080 DNxHD 8-bit HQ/SQ/LB, 10-bit 444/HQX up to 120 fps
Sensor Size	29.90 mm x 15.77 mm (Diagonal: 33.80 mm)
Sensor Type	HELIUM 35.4 Megapixel CMOS
Weight	3.35 lbs (BRAIN with Integrated Media Bay)

See All

Resources

Helium Operation Guide

Sample R3D Files

Red Tools

Reviews

See Reviews

Rental Period	Lenscap+	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$53.00	$382.00	$435.00	$145.00
4 days	$56.00	$409.00	$465.00	$116.25
7 days	$75.00	$545.00	$620.00	$88.57
10 days	$101.00	$736.00	$837.00	$83.70
14 days	$131.00	$954.00	$1085.00	$77.50
21 days	$176.00	$1281.00	$1457.00	$69.38
30 days	$221.00	$1608.00	$1829.00	$60.97
45 days	$289.00	$2098.00	$2387.00	$53.04
60 days	$338.00	$2453.00	$2791.00	$46.52
90 days	$435.00	$3161.00	$3596.00	$39.96

Rental Period	Lenscap	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$35.00	$382.00	$417.00	$139.00
4 days	$38.00	$409.00	$447.00	$111.75
7 days	$50.00	$545.00	$595.00	$85.00
10 days	$68.00	$736.00	$804.00	$80.40
14 days	$88.00	$954.00	$1042.00	$74.43
21 days	$118.00	$1281.00	$1399.00	$66.62
30 days	$148.00	$1608.00	$1756.00	$58.53
45 days	$193.00	$2098.00	$2291.00	$50.91
60 days	$225.00	$2453.00	$2678.00	$44.63
90 days	$290.00	$3161.00	$3451.00	$38.34

Rental Period	Rental Price	Price Per Day (Approx.)
3 days	$382.00	$127.33
4 days	$409.00	$102.25
7 days	$545.00	$77.86
10 days	$736.00	$73.60
14 days	$954.00	$68.14
21 days	$1281.00	$61.00
30 days	$1608.00	$53.60
45 days	$2098.00	$46.62
60 days	$2453.00	$40.88
90 days	$3161.00	$35.12
