Sony FR7 Cinema Line PTZ Camera

$598.00

7 Day

Rental

Arrival Date

Return Date

Pricing Chart

Shipping Rates

Interested in purchasing?

Includes

Sony FR7 Cinema Line PTZ Camera
Non-Polarized Cable
(2) 15mm 4-inch Rods
AC Adapter
15mm Lens Support
RMT-RC1 Remote

Resources

Manual

SETUP Dip-Switch Configuration Info

Compatible Lenses

Sony FR7 Cinema Line PTZ Camera

The Sony FR7 Cinema Line PTZ Camera is a sleek, full-frame PTZ VISCA-supported camera that’s compatible with over 70 Sony E-mount lenses ranging from 12 to 1200mm. Key features include:

4K full-frame sensor
Variable electronic ND filter
Up to 100 preset positions
Supports up to UHD 4K120 video

PTZ Paradise. The Sony FR7 Cinema Line PTZ Camera combines a 4K full-frame sensor and compatibility with Sony E-mount lenses to produce outstandingly expressive, cinematic imagery. This large image sensor provides 15+ stops of dynamic range, captures up to UHD 4K120 video, offers live streaming, and enables you to create shallow depth-of-field bokeh effects. Its base ISO of 800 is expandable from 12,800 to 409,600 for capturing optimal video in an array of lighting conditions.

Compatibility and Functions. The FR7 PTZ offers compatibility with a wide array of E-Mount and G Master lenses. Currently, it takes up to 70 different lenses ranging from 12mm to 1200mm. Sony S-Log3 enables you to capture sharp and wide color, while Hybrid Log Gamma (HLG) creates nuanced contrast. The integrated ND filter offers variable ND filtration ranging from 2 stops to 7 stops, allows changes in exposure without affecting your depth of field, and creates shallow depth-of-field effects by adding the ND and opening the iris. The FR7 supports the VISCA protocol from Sony as well.

No Losing Control Here. The IP remote function can be used for pan, tilt, zoom (PTZ), focus, recording, playback, and other camera settings. For full PTZ control, you must be using a compatible Sony Power Zoom series lens. Pan and tilt functions move smoothly and enable you to unobtrusively zoom in on the action and reframe accordingly. Using the separately available RM-IP500 Controller puts you in control via a joystick zoom rocker and buttons. Fast hybrid autofocus with face detection and touch tracking is also included and enable you to keep even dynamic action in focus. Please note that a Sony Power Zoom series lens is required for full PTZ control.

Cine-Style Recording. With the S-Cinetone picture profile, you’re able to bring a cinematic look to your PTZ capture and match footage from other Sony cameras. The Cine EI mode with MLUT management can be used with S-Log3 or raw recording, and XAVC recording with metadata capture supports up to 10-bit, 4:2:2 color and HDR recording.

Optional Zoom Control. If getting more precise zoom control on your lens is on the list for you, we offer the Chrosziel Zoom Motor Unit to rent as a separate accessory. This device attaches to the bottom of the FR7 and will work with most lenses ranging from 8mm to 120mm.

Q & A

Do I need anything else?

Depending on use, you may need a variety of accessories, cables, or monitors.
We recommend checking out the Chrosziel Zoom Motor Unit or Sony RM-IP500/1 Professional Remote Controller. Take a peep at the recommended section of your screen for more compatible accessories.

Why won't this camera boot up?

If the 15mm Lens Support is pushed up on the rods and left dangling, it can get caught during the boot process and prevent the camera from booting up.
Make sure to push the Lens Support up and back and tighten it before trying to boot the camera.

I can’t get the RM-IP500 controller to connect to the FR7 camera. What can I do?

If you can’t get the RM-IP500 controller to connect to the FR7 camera, make sure that SETUP dip switch #3 on the back of the camera is flipped on to enable VISCA over IP control and then reboot the camera.
You should also verify that the FR7 camera and the RM-IP500 controller are on the same network and subnet configuration.
If you have any questions, please contact us.

Specifications

Brand	Sony
Camcorder Type	PTZ and Cinema
Camera Type	Camcorder
Control	Presets 3 via IR 100 via IP Move Speed Pan: 0.02 to 60°/sec Tilt: 0.02 to 60°/sec Movement Range Pan: 340° (-170 to 170°) Tilt: 225° (-30 to 195°) Tally Light Yes Supported Control Protocols IR VISCA
Environmental	Operating Temperature 32 to 104°F Storage Temperature -4 to 140°F
Exposure Control	Shutter Type Electronic Rolling Shutter Shutter Speed 1/8000 to 1 Second ISO Sensitivity 800 to 12,800 (Extended: 409,600) Gain -3 to 30 dB Advertised Dynamic Range 15 Stops Flip / Mirror Support Image Flip White Balance 2000 to 15,000K Presets ATW, Set A
General	Mounting 2 × 1/4"-20 Female for Tripod Netflix Approved Yes Sound Level NC35 Dimensions (W x H x D) 11.4 × 9.2 × 8.9″ Weight 10.1 lb
Imaging	Lens Mount Sony EM Sensor Type CMOS Sensor Sensor Resolution Actual: 12.9 Megapixel Effective: 10.3 Megapixel Lens Communication Yes, with Autofocus Support Built-In ND Filter 2 to 7 Stop Electronic ND Filter Focus Control Autofocus Autofocus Points Phase Detection: 627
Interface	Media/Memory Card Slot Dual Slot: CFexpress Type A / SD Video I/O 1 x BNC (12G-SDI) Output 1 x SFP+ Output 1 x HDMI Output Audio I/O 1 x XLR 5-Pin Mic/Line (+48 V Phantom Power) Input Other I/O 1 x BNC (Timecode) 1 x RJ45 (LAN) Control 1 x BNC (Genlock) 1 x RJ45 (Tally)
Item Type	Camera and Cinema Cameras
Power	PoE Support PoE++ 802.3bt Power I/O 1 x Barrel (19.5VDC) Input Power Consumption PoE: 71.3 W Power Supply: 80 W
Video Capture	External Recording Modes Raw 16-Bit via SDI/BNC 4096 × 2160 at 23.98/24.00/25/29.97/50/59.94 fps 3840 × 2160 at 23.98/25/29.97/50/59.94 fps 1920 × 1080 at 23.98/24.00/25/29.97/50/59.94 fps HDMI 4096 × 2160 at 23.98/24.00/25/29.97/50/59.94 fps 3840 × 2160 at 23.98/25/29.97/50/59.94 fps 1920 × 1080 at 23.98/24.00/25/29.97/50/59.94 fps 720 × 480 at 59.94 fps 720 × 576 at 50 fps Internal Recording Modes XAVC-I 4:2:2 10-Bit DCI 4K (4096 × 2160) at 24.00/25/29.97/50/59.94 fps [240 to 600 Mb/s VBR] UHD 4K (3840 × 2160) at 25/29.97/50/59.94 fps [240 to 600 Mb/s VBR] 1920 × 1080 at 25/29.97/50/59.94 fps [89 to 222 Mb/s] XAVC-L UHD 4K (3840 × 2160) at 25/29.97/50/59.94 fps [100 to 150 Mb/s VBR] 1920 × 1080 at 25/29.97/50/59.94 fps [35 to 50 Mb/s VBR] Audio Recording 4-Channel 24-Bit 48 kHz LPCM Audio Gamma Curve HDR-HLG Rec709 S Cinetone Sony S-Log 3 Standard IP Streaming NDI\|HX, RTSP, SRT:640 × 360 to 4096 × 2160 (0.5 to 80.00 Mb/s)

See All

Includes

Sony FR7 Cinema Line PTZ Camera
Non-Polarized Cable
(2) 15mm 4-inch Rods
AC Adapter
15mm Lens Support
RMT-RC1 Remote

Specifications

Brand	Sony
Camcorder Type	PTZ and Cinema
Camera Type	Camcorder
Control	Presets 3 via IR 100 via IP Move Speed Pan: 0.02 to 60°/sec Tilt: 0.02 to 60°/sec Movement Range Pan: 340° (-170 to 170°) Tilt: 225° (-30 to 195°) Tally Light Yes Supported Control Protocols IR VISCA
Environmental	Operating Temperature 32 to 104°F Storage Temperature -4 to 140°F
Exposure Control	Shutter Type Electronic Rolling Shutter Shutter Speed 1/8000 to 1 Second ISO Sensitivity 800 to 12,800 (Extended: 409,600) Gain -3 to 30 dB Advertised Dynamic Range 15 Stops Flip / Mirror Support Image Flip White Balance 2000 to 15,000K Presets ATW, Set A
General	Mounting 2 × 1/4"-20 Female for Tripod Netflix Approved Yes Sound Level NC35 Dimensions (W x H x D) 11.4 × 9.2 × 8.9″ Weight 10.1 lb
Imaging	Lens Mount Sony EM Sensor Type CMOS Sensor Sensor Resolution Actual: 12.9 Megapixel Effective: 10.3 Megapixel Lens Communication Yes, with Autofocus Support Built-In ND Filter 2 to 7 Stop Electronic ND Filter Focus Control Autofocus Autofocus Points Phase Detection: 627
Interface	Media/Memory Card Slot Dual Slot: CFexpress Type A / SD Video I/O 1 x BNC (12G-SDI) Output 1 x SFP+ Output 1 x HDMI Output Audio I/O 1 x XLR 5-Pin Mic/Line (+48 V Phantom Power) Input Other I/O 1 x BNC (Timecode) 1 x RJ45 (LAN) Control 1 x BNC (Genlock) 1 x RJ45 (Tally)
Item Type	Camera and Cinema Cameras
Power	PoE Support PoE++ 802.3bt Power I/O 1 x Barrel (19.5VDC) Input Power Consumption PoE: 71.3 W Power Supply: 80 W
Video Capture	External Recording Modes Raw 16-Bit via SDI/BNC 4096 × 2160 at 23.98/24.00/25/29.97/50/59.94 fps 3840 × 2160 at 23.98/25/29.97/50/59.94 fps 1920 × 1080 at 23.98/24.00/25/29.97/50/59.94 fps HDMI 4096 × 2160 at 23.98/24.00/25/29.97/50/59.94 fps 3840 × 2160 at 23.98/25/29.97/50/59.94 fps 1920 × 1080 at 23.98/24.00/25/29.97/50/59.94 fps 720 × 480 at 59.94 fps 720 × 576 at 50 fps Internal Recording Modes XAVC-I 4:2:2 10-Bit DCI 4K (4096 × 2160) at 24.00/25/29.97/50/59.94 fps [240 to 600 Mb/s VBR] UHD 4K (3840 × 2160) at 25/29.97/50/59.94 fps [240 to 600 Mb/s VBR] 1920 × 1080 at 25/29.97/50/59.94 fps [89 to 222 Mb/s] XAVC-L UHD 4K (3840 × 2160) at 25/29.97/50/59.94 fps [100 to 150 Mb/s VBR] 1920 × 1080 at 25/29.97/50/59.94 fps [35 to 50 Mb/s VBR] Audio Recording 4-Channel 24-Bit 48 kHz LPCM Audio Gamma Curve HDR-HLG Rec709 S Cinetone Sony S-Log 3 Standard IP Streaming NDI\|HX, RTSP, SRT:640 × 360 to 4096 × 2160 (0.5 to 80.00 Mb/s)

See All

Resources

Manual

SETUP Dip-Switch Configuration Info

Compatible Lenses

Reviews

See Reviews

Rental Period	Lenscap+	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$88.00	$422.00	$510.00	$170.00
4 days	$95.00	$451.00	$546.00	$136.50
7 days	$126.00	$598.00	$724.00	$103.43
10 days	$170.00	$804.00	$974.00	$97.40
14 days	$221.00	$1039.00	$1260.00	$90.00
21 days	$296.00	$1392.00	$1688.00	$80.38
30 days	$372.00	$1745.00	$2117.00	$70.57
45 days	$485.00	$2274.00	$2759.00	$61.31
60 days	$567.00	$2656.00	$3223.00	$53.72
90 days	$731.00	$3420.00	$4151.00	$46.12

Rental Period	Lenscap	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$59.00	$422.00	$481.00	$160.33
4 days	$63.00	$451.00	$514.00	$128.50
7 days	$84.00	$598.00	$682.00	$97.43
10 days	$113.00	$804.00	$917.00	$91.70
14 days	$147.00	$1039.00	$1186.00	$84.71
21 days	$197.00	$1392.00	$1589.00	$75.67
30 days	$248.00	$1745.00	$1993.00	$66.43
45 days	$323.00	$2274.00	$2597.00	$57.71
60 days	$378.00	$2656.00	$3034.00	$50.57
90 days	$487.00	$3420.00	$3907.00	$43.41

Rental Period	Rental Price	Price Per Day (Approx.)
3 days	$422.00	$140.67
4 days	$451.00	$112.75
7 days	$598.00	$85.43
10 days	$804.00	$80.40
14 days	$1039.00	$74.21
21 days	$1392.00	$66.29
30 days	$1745.00	$58.17
45 days	$2274.00	$50.53
60 days	$2656.00	$44.27
90 days	$3420.00	$38.00
